E037  $3525


Short sword Date of Construction: 2005-12

Blade Characteristics
   Steel Type: Damascus
   Composition  :  O1/Nickel
   Billet #  :  5-Nov
   Number of Layers: ~100
   Pattern: Twist
   Etch: Medium
   Polish: 600-1200

Dimension (inches)
      Length: 10.5
      Max Thickness: 0.25
      Min Thickness: 0.1
Handle Characteristics
   Grip Material: Rosewood
   Grip Type : Guard & pommel
   Fittings Material: Sterling Silver
   Fasteners: Allen Bolt

Dimension (inches)
      Length: 5.875
      Max Thickness: 1.212
      Min Thickness: 1.062
      Max Height: 1.575
      Min Height: 1.124
Heat Treatment
   Austenization & Quenching
      Heat Source: Lava Pool
      Temperature (F): 1500
      Quench material: Salt Pot
      Quench temperature (F): 475

Tempering
      Temperature (F): N/A
      Duration (hrs): 2
      Repetitions: N/A


Full sheath provided

Comments
Nikolai Stefanovitch Compositov IV = Nambam 2 - copper habaki, cast silver pommel & handle throat ring with dragon menuki and bahia grass seed embroidery, nickel silver guard with vine file pattern, blade spine with same, sheath with silver chape and throat ring with dragon menuki. This is a prize winning blade and is named as it is since it is a nickel-1095 twist composite of 4 bars with an O1 edge bar - and was made by me (Stephen=Stefan). This is one FANCY blade!

Nikolai is a NamBam2 blade that is definitely over the top with regards to enhancements. Due to the mass of the blade, there is a safety pin inside of the mosiac pin -- an 8x32 set screw


n/a  =  not applicable
