| Collectable | Date of Construction: 2020-03 |
| Blade Characteristics Steel Type: 203E & 1084 -Powder Composition : Twisted Billet # : n/a Number of Layers: n/a Pattern: Twist Etch: Medium Polish: Satin Dimension (inches) Length: 13.00 Max Thickness: 0.21 Min Thickness: 0.06 |
Handle Characteristics Grip Material: Ziricote Grip Type : Dagger Fittings Material: mild steel blackened Fasteners: 1/4" pommel bolt & pin Dimension (inches) Length: 6.5 Max Thickness: 0.945 Min Thickness: 0.568 Max Height: 1.382 Min Height: 0.747 |
Heat Treatment Austenization & Quenching Heat Source: Austenizer Temperature (F): 1500 Quench material: Oil Quench temperature (F): ambient Tempering Temperature (F): 400 Duration (hrs): 2 Repetitions: n/a |
Comments
| Blade was made of 2 rods of 203E ~ 5/16 diameter & 24" long - each was bend into a 'U' and one was twisted CW, the other CCW. Place in a 'canoe' with powder metal, welded & drawn out {after removing the canoe}. |
n/a = not applicable
